GAS BURNERS ON STAGE RIELLO R40 FS 10

FS 10 GAS 1

GAS BURNERS ON STAGE RIELLO R40 FS 10

RIELLO BURNER R40 FS 10 PEMBAKAR GAS (SATU TAHAP) FS10 42 ÷ 116 kW

TECHNICAL DATA Model RIELLO 40 FS10 Type 564T30

Heat output (Hi) (1) min – max kW: 42 116
kcal/h: 36,000 100,000
Fuel Family 2 – NCV 8 12 kWh/m3 – 7,000 10,340 kcal/m3
Fuel Family 2 – Pressure: min. 18 mbar – max. 360 mbar
Operation: Intermittent (FS1)
Use Boilers: water and diathermic oil
Ambient temperature: °C 0 – 50
Combustion air temperature: °C max 60
Electrical supply: 1/230V/50Hz
Fan motor rpm – rad/s: 2800 – 294
V – Hz: 230 – 50
W: 90
A: 0.75
Ignition transformer: Primary 230V / 1.8A – Secondary 8 kV / 30 mA
Capacitor F 4
Absorbed electrical power: kW 0.13
Protection level IP40
Weight: kg 16
Noise levels (2) Sound pressure: 63.1
Sound power dB(A): 74.7









RIELLO BURNER R40 FS 20 PEMBAKAR GAS (SATU TAHAP) FS20 81 ÷ 220 kW

TECHNICAL DATA Model RIELLO 40 FS20 Type 564T30

Heat output (Hi) (1) min – max kW: 81 – 220
kcal/h: 70,000 – 189,000
Fuel Family 2 – NCV 8 – 12 kWh/m3 – 7,000 – 10,340 kcal/m3
Fuel Family 2 – Pressure: min. 26 mbar – max. 360 mbar
Operation: Intermittent (FS1)
Use Boilers: water and diathermic oil
Ambient temperature: °C 0 – 50
Combustion air temperature: °C max 60
Electrical supply: 1/230V/50Hz
Fan motor rpm – rad/s: 2750 – 288
V – Hz: 230 – 50
W: 150
A: 1.3
Ignition transformer: Primary 230V / 1.8A – Secondary 8 kV / 30 mA
Capacitor F 5
Absorbed electrical power: kW 0.25
Protection level IP40
Weight: kg 16
Noise levels (2) Sound pressure: 66.8Sound power dB(A): 78.5









Perlengkapan standar:
– Layar insulasi flensa
– Sekrup dan mur untuk memasang flensa ke boiler
– Soket 7 kutub
– Engsel
– Reduksi nipel Rp 1/2” – Rp 3/8” (khusus R40 FS3)
– Grommet
– Buku pegangan instruksi untuk instalasi, penggunaan dan pemeliharaan
– Katalog suku cadang.



Hubungi Kami

PT. SUMBER TEKNIK INDUSTRI

Jl. Mangga Pesona Lebak Wangi 2 blok A3 no 15 Kec, Sepatan Timur Kab, tangerang Provinsi Banten 15521

Whatsapp : 0852 8276 2784

Mobile      : 0852 82762 784

Email        : idmslamet@gmail.com

Website    : https://boilersburner.com

Referensi: https://www.rielloburners.co.uk/products/gas-burners/one-stage/riello-40-fs-series/3756435
