BURNER RIELLO  RL 70 255/474 ÷ 830 kW LIGHT OIL TWO STAGE

TECHNICAL DATA MODEL : RL70 TYPE : 660 T1

OUTPUT DELIVERY (1) 2nd stage : 474 – 830 kW , 408 – 714 Mcal/h , 40 – 70 kg/h
OUTPUT DELIVERY (1) 1st stage : 255 – 474 kW , 219 – 408 Mcal/h , 21.5 – 40 kg/h
FUEL : LIGHT OIL/SOLAR
Net calorific value : 11.8 kWh/kg, 10,2 (10.200 kcal/kg),
Density : 0.82 – 0.85 kg/dm
Viscosity at 20 °C mm2/s max 6 (1,5 °E – 6 cSt)
OPERATION – Intermittent (min. 1 stop in 24 hours).
Two-stage (high and low flame) and single-stage (all – nothing).
NOZZLES number 2
STANDARD APPLICATIONS Boilers: water, steam, diathermic oil
AMBIENT TEMPERATURE : °C 0 – 40
COMBUSTION AIR TEMPERATURE : °C max 60
PUMP delivery (at 20 bar) kg/h 107
pressure range bar : 10-20
fuel temperature : ° C max 60
ELECTRICAL PROTECTION : IP 44
NOISE LEVELS (2) : dBA 75,0
ELECTRICAL DATA
Motor IE1
POWER SUPPLY – V: 230 – 400 with neutral ~ +/- 10%, Hz: 50 – three-phase
ELECTRICAL MOTOR – rpm: 2800, kW: 1,1, V: 230/400, A: 4.7/2.7
IGNITION TRASFORMER – V1 – V2: 230 V – 2 x 5 kV, I1 – I2: 1.9 A – 30 mA
ELECTRICAL POWER CONSUMPTION – kW max: 2.0
Motor IE2
POWER SUPPLY – V: 230 – 400 with neutral ~ +/- 10%, Hz: 50 – three-phase
ELECTRICAL MOTOR – rpm: 2860, kW: 1,1, V: 230/400, A: 4.1/2.4
IGNITION TRASFORMER – V1 – V2: 230 V – 2 x 5 kV, I1 – I2: 1.9 A – 30 mA
ELECTRICAL POWER CONSUMPTION – kW max: 1.9

BURNER RIELLO  RL 100 356/711 ÷ 1186 kW  LIGHT OIL TWO STAGE

 DATA TEKCNICAL BURNER RIELLO RL 100

Burner operation : 2 Tahap (Two stage / Dua Nozzle)
Modulation ratio at max. output : 2 ÷ 1
Heat output : 356/711÷1186 kW
Heat output : 306/612÷1020 Mcal/h
Bahan Bakar : Solar 30-100 Liter/jam
Tipe Control box : Siemens RMO 88
Tipe Pompa : Suntec AJ 6CC
Motor electrical power : 1,8 kW
Ignition transformer V1 – V2 : 230V – 2x5kV / 1,9A –
30mA
