RIELLO BURNER LIGHT OIL TWO STAGE RL 50 148/296 ÷ 593 kW

Data Tecknical Riello RL 50

Electrical supply Ph/Hz/V -5 Auxiliary electrical supply Ph/Hz/V -3

Control box type RMO 88.53

Total electrical power kW 1,4

Auxiliary electrical power kW 0,3

Protection level IP 44 Power electric motor kW 1,1

Rated motor current A 4.7 – 2.7

Motor start current A 24.5 – 14

Motor protection level IP 55

Ignition transformer V1 – V2 230V – 2x5kV

BURNER RIELLO RL 64 MZ LIGHT OIL TWO STAGE 206/391 ÷ 830 kW

DATA TEKNIKAL BURNER RIELLO RL 64MZ

Electrical Power Consumption (W max)1800

Electrical Supply (V, Hz)230 – 400 VAC

with neutal ± 10%, 50/60 – three phase

Fuel Light Oil Operat Intermittent (min. 1 stop in 24 hours)

Two-stage (high and low flame)

and one-stage (all-nothing)

Output 2nd Stage (kg/h) 33-70 2nd Stage (kW) 391-830 2nd

Stage (Mcal/h) 336-714 min. 1st Stage (kg/h) 17,4-33 min. 1st

Stage (kW) 206-391 min. 1st Stage (Mcal/h) 177-296

RIELLO BURNER LIGHT OIL TWO STAGE RL 70 255/474 ÷ 830 kW

TECHNICAL DATA MODEL : RL70 TYPE : 660 T1

OUTPUT DELIVERY (1) 2nd stage : 474 – 830 kW , 408 – 714 Mcal/h , 40 – 70 kg/h
OUTPUT DELIVERY (1) 1st stage : 255 – 474 kW , 219 – 408 Mcal/h , 21.5 – 40 kg/h
FUEL : LIGHT OIL/SOLAR
Net calorific value : 11.8 kWh/kg, 10,2 (10.200 kcal/kg),
Density : 0.82 – 0.85 kg/dm
Viscosity at 20 °C mm2/s max 6 (1,5 °E – 6 cSt)
OPERATION – Intermittent (min. 1 stop in 24 hours).
Two-stage (high and low flame) and single-stage (all – nothing).
NOZZLES number 2
STANDARD APPLICATIONS Boilers: water, steam, diathermic oil
AMBIENT TEMPERATURE : °C 0 – 40
COMBUSTION AIR TEMPERATURE : °C max 60
PUMP delivery (at 20 bar) kg/h 107
pressure range bar : 10-20
fuel temperature : ° C max 60
ELECTRICAL PROTECTION : IP 44
NOISE LEVELS (2) : dBA 75,0
ELECTRICAL DATA
Motor IE1
POWER SUPPLY – V: 230 – 400 with neutral ~ +/- 10%, Hz: 50 – three-phase
ELECTRICAL MOTOR – rpm: 2800, kW: 1,1, V: 230/400, A: 4.7/2.7
IGNITION TRASFORMER – V1 – V2: 230 V – 2 x 5 kV, I1 – I2: 1.9 A – 30 mA
ELECTRICAL POWER CONSUMPTION – kW max: 2.0
Motor IE2
POWER SUPPLY – V: 230 – 400 with neutral ~ +/- 10%, Hz: 50 – three-phase
ELECTRICAL MOTOR – rpm: 2860, kW: 1,1, V: 230/400, A: 4.1/2.4
IGNITION TRASFORMER – V1 – V2: 230 V – 2 x 5 kV, I1 – I2: 1.9 A – 30 mA
ELECTRICAL POWER CONSUMPTION – kW max: 1.9
