GAS BURNERS TWO STAGE RIELLO GAS 3/2

BURNER GAS 3 2

GAS BURNERS TWO STAGE RIELLO GAS 3/2

TWO STAGE GAS BURNERS RIELLO GAS 3/2 80/130 ÷ 350 kW

Technical Datasheet Type Gas 3/2
MODEL : GAS 3/2
Burner operation mode : Two stage
Modulation ratio at max. output : 2 ÷ 1
Servomotor : LKS210
Heat output : kW 80/130÷350
Heat output : Mcal/h 69/112÷301
Working temperature °C : min./max. 0/40
Net calorific value LPG gas kWh/Nm3 : 25,8
Density LPG gas kg/Nm3 : 2,02
Output LPG gas Nm3/h : 3/5÷13,5
Control box Type : RMG
Motor electrical power kW : 0,4
Ignition transformer V1 – V2 : 230V-1×8 kV 1A – 20 mA





TWO STAGE GAS BURNERS RIELLO GAS 4/2 120/180 ÷ 470 kW

Technical Datasheet Type Gas 4/2
MODEL : GAS 4/2
Burner operation mode : Two stage
Modulation ratio at max. output : 2 ÷ 1
Servomotor : LKS210
Heat output : kW 120/180÷470
Heat output : Mcal/h 104/155÷404
Working temperature °C : min./max. 0/40
Net calorific value LPG gas kWh/Nm3 : 25,8
Density LPG gas kg/Nm3 : 2,02
Output LPG gas Nm3/h : 5/7÷18
Control box Type : RMG
Motor electrical power kW : 0,54
Ignition transformer V1 – V2 : 230V-1×8 kV 1A – 20 mA





TWO STAGE GAS BURNERS RIELLO GAS 5/2 155/320 ÷ 660 kW

Technical Datasheet Type Gas 5/2
MODEL : GAS 5/2
Burner operation mode : Two stage
Modulation ratio at max. output : 2 ÷ 1
Servomotor : LKS210
Heat output : kW 155/320÷660
Heat output : Mcal/h 133/275÷568
Working temperature °C : min./max. 0/40
Net calorific value LPG gas kWh/Nm3 : 25,8
Density LPG gas kg/Nm3 : 2,02
Output LPG gas Nm3/h : 6/12÷25,5
Control box Type : RMG
Motor electrical power kW : 0,85
Ignition transformer V1 – V2 : 230V-1×8 kV 1A – 20 mA





TWO STAGE GAS BURNERS RIELLO GAS 6/2 300/520 ÷ 1050 kW

Technical Datasheet Type Gas 6/2
MODEL : GAS 6/2
Burner operation mode : Two stage
Modulation ratio at max. output : 2 ÷ 1
Servomotor : LKS210
Heat output : kW 300/520÷1050
Heat output : Mcal/h 258/447÷903
Working temperature °C : min./max. 0/40
Net calorific value LPG gas kWh/Nm3 : 25,8
Density LPG gas kg/Nm3 : 2,02
Output LPG gas Nm3/h : 11,5/20÷41
Control box Type : RMG
Motor electrical power kW : 1,7
Ignition transformer V1 – V2 : 230V-1×8 kV 1A – 20 mA
